Milesight | SKU: SG50-L08GL-868M PN: 30W

8% off

Milesight SG50 | Solar-Powered LoRaWAN Gateway

€725,00 €792,00

Shipping calculated at checkout.

A professional all-in-one solar-powered gateway designed for autonomous LoRaWAN networking in remote or off-grid locations.

• Off-Grid Ready: Integrated battery and solar power management.
• High Efficiency: Available in 30W and 45W solar panel variants.
• Cellular Backhaul: Reliable 4G LTE connectivity for data uplink.

Solar Panel Power

Secure Payment & Warranty

Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
Quality Guaranteed: All professional IoT hardware is backed by a 2-year manufacturer warranty and technical support from our engineering experts at shopioT.

Delivery and Shipping

Reliable, tracked, and fast global shipping via FedEx Express. Your professional IoT hardware is dispatched from our EU-based warehouse within 2 business days.

Add a stand out message for your customers

Description

The Milesight SG50 is a specialized Solar-Powered LoRaWAN Gateway engineered to eliminate the barriers of power and connectivity in remote environments. By integrating a high-performance gateway with a built-in battery and a dedicated solar panel—available in 30W and 45W models—it provides a truly autonomous networking solution for outdoor industrial and agricultural applications.

Autonomous Off-Grid Intelligence

Industrial Ruggedness Housed in an IP67-rated enclosure with UV protection, designed to withstand extreme outdoor conditions while providing stable 4G LTE backhaul.

Smart Energy Management Internal battery heater for cold-weather charging and real-time monitoring of solar efficiency and power status via the Milesight IoT Cloud.

Remote Infrastructure Scenarios

• Smart Agriculture: Deploy deep in fields or orchards to collect soil and environmental data without needing electrical grid access.

• Environmental Monitoring: Track air quality or water levels in remote basins and mountains with full solar autonomy.

• Industrial Asset Tracking: Monitor outdoor storage yards or construction sites where temporary but robust LoRaWAN coverage is required.

What is in the Box?

• 1 x Milesight SG50 Solar Gateway Unit

• 1 x Solar Panel (30W or 45W Variant)

• 1 x Mounting Bracket & U-Bolt Kit

• 1 x Quick Start Guide

Product Certifications

CE FCC IP67 RoHS

Specifications

Primary Communication Protocol

LoRaWAN
Frequency/Region

EU868
Antenna Type

External (N-Type)
LoRaWAN Channels

8 Channels
Configuration Method

Wi-Fi, Web GUI (HTTP/HTTPS)
Activation Method

OTAA, ABP
Environment Rating

Outdoor
IP Rating

IP67
Operating Temperature

-30°C to 70°C
Enclosure Material

Metal
Battery Type

Li-MnO2
Battery Capacity

25000mAh
Power Consumption

Typical 0.8W
Measurement Technology
- Solar-Powered Autonomy: Integrated power management system utilizing solar energy to power the gateway while charging internal batteries.
- Ultra-Low Power Design: Typical consumption of just 0.8W, allowing for up to 4 days of operation without sunlight (25Ah battery).
- SX1302 Chipset: Industrial-grade LoRa engine capable of handling high traffic from up to 2,000 end-nodes.
- Smart Energy Logic: Automatic Wi-Fi shutdown during low battery status and dynamic charging adjustments based on temperature.
- Global Backhaul: 4G LTE/GSM connectivity ensures data transmission from regions without Ethernet or Fiber infrastructure.
Measurement Range
Available Solar Panel Configurations:
- 30W Version (Default): Rated 15V/2A, 533 x 303 mm. Ideal for regions with standard solar irradiance.
- 45W Version (Optional): Rated 15V/3A, 570 x 380 mm. Recommended for areas with shorter sunlight duration or heavy data traffic.
- Cell Type: High-efficiency Monocrystalline Silicon for both models.
Measurement Accuracy
- Transmission Range: Up to 15km line-of-sight (rural) and 2km in dense urban environments.
- Industrial Protection: IP67-rated waterproof housing with an integrated vent plug to prevent internal condensation.
- GPS Precision: Built-in GNSS for remote asset tracking and location-based network management.
Measurement Resolution
- Sensitivity: -140 dBm @ 292bps for superior signal penetration.
- Traffic Handling: 8 half-duplex channels supporting a high density of Class A, B, and C devices.
- Visual Indicators: RGB LED area for System, LTE, and Wi-Fi status diagnostics.
Interfaces (I/O)

Nano SIM Slot, M12 Connector (Power), USB Type-C
Monitoring Parameters

Battery Voltage, Signal Strength

Document Library

SG50 Datasheet

SG50 User Manual
