SenseCAP  |  SKU: 114992871

Seeed Studio SenseCAP S2105 | LoRaWAN Soil Moisture, Temperature & EC Sensor

Price incl. 19% VAT
€170,00
Price excl. VAT
€142,86
Shipping calculated at checkout. Shipping policy

The Seeed Studio S2105 is a LoRaWAN soil sensor for moisture, temperature and EC.

  • Three soil readings: FDR moisture, temperature and EC (0–23 dS/m)
  • Long range, easy setup: LoRaWAN Class A, 2–10 km, Bluetooth setup
  • Built for the field: IP66, −40 to +85 °C, 10-year battery

VAT & Business Purchases

Prices include VAT at the rate of your EU delivery country, so the price shown is the price you pay. EU businesses with a valid VAT number can buy VAT-free: enter your company name and VAT number at checkout and VAT is removed under the intra-community reverse-charge rules. Orders delivered within Cyprus always include Cyprus VAT.

Secure Payment & Warranty
  • Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
  • B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
  • Warranty & Support: Consumer purchases are covered by the 2-year legal guarantee of conformity, and manufacturer warranty terms apply per brand. Our engineering team at shopioT provides technical support.

Delivery and Shipping

Tracked delivery to Cyprus, all EU member states, the United Kingdom and Switzerland via ACS Courier, Cyprus Post or FedEx. Orders ship from our warehouse in Nicosia, Cyprus, typically within 1–3 business days. See our Shipping Policy for delivery times.

EU business? Enter your company name and a valid EU VAT number at checkout to remove VAT (reverse charge).

Description

The Seeed Studio SenseCAP S2105 is a battery-powered wireless LoRaWAN® soil sensor that simultaneously measures soil moisture (volumetric water content), soil temperature, and electrical conductivity (EC) using FDR sensing — the essentials for precision irrigation and crop health.

Soil EC indicates salinity and influences nutrient availability and microbial activity, so the S2105 gives a fuller picture than moisture alone. With up to 10-year battery life, an IP66 enclosure rated −40 °C to +85 °C, and 2–10 km LoRaWAN range, it's built for harsh outdoor agriculture — and sets up in minutes via Bluetooth, no tools or wiring required.

Core Capabilities

3-in-1 Soil Sensing (Moisture, Temp, EC) FDR soil moisture (0–100% VWC, ±3%), temperature (−40 to +80 °C, ±0.5 °C), and electrical conductivity (0–23 dS/m, ±5%) — measuring water, heat, and salinity for smarter irrigation and fertigation.
Long-Range LoRaWAN, One Global SKU Built on the Wio-E5 (LoRaWAN v1.0.3 Class A) with 19 dBm Tx and −136 dBm sensitivity for 2 km urban / 10 km line-of-sight range. A single SKU supports 7 frequency plans (EU868, US915, AU915, AS923, KR920, IN865, RU864).
10-Year Battery & Rugged IP66 A replaceable D-size ER34615 Li-SOCl₂ battery (19 Ah) gives up to 10 years of operation. The IP66 enclosure (−40 to +85 °C) shrugs off UV, heavy rain, and dust, with a 5 m soil-probe cable for flexible burial depth.
No-Code Bluetooth Setup Built-in Bluetooth lets you configure and update the sensor in four steps using the free SenseCAP Mate app — no programming. Validated through six reliability tests for dependable performance in extreme conditions.

Typical Applications

Precision Agriculture & Irrigation: Schedule irrigation and fertigation from real soil moisture and EC data to save water, boost yield, and avoid over/under-watering across fields.
Greenhouses & Horticulture: Monitor root-zone moisture, temperature, and salinity to optimise growth and nutrient delivery in controlled environments.
Turf, Landscaping & Sports Fields: Maintain healthy turf and green spaces with data-driven watering and salinity management.
Environmental & Research Monitoring: Build distributed soil-monitoring networks for hydrology, climate, and land-management research with long-range, low-maintenance sensors.

Technical Integration

Key points for adding the S2105 to your LoRaWAN network:

Connectivity: LoRaWAN® v1.0.3 Class A; a single global SKU supporting 7 frequency plans (863–928 MHz: EU868, US915, AU915, AS923, KR920, IN865, RU864).
Network server & platform: Works with any standard LoRaWAN gateway and network server (e.g. The Things Stack, ChirpStack) or the SenseCAP platform.
Configuration: No-code Bluetooth setup via the free SenseCAP Mate app; the frequency plan is set on first power-up and can be changed any time.
Power: Pre-installed, replaceable D-size ER34615 Li-SOCl₂ battery (19 Ah) for up to 10 years of operation.
Probe & environment: 5 m soil-probe cable, 405 g; IP66 enclosure rated −40 °C to +85 °C for UV, rain, and dust.
Setup help: For frequency/gateway selection or deployment support, contact the shopioT technical team.

Frequently Asked Questions

What does the S2105 measure, and why does EC matter?

Soil moisture (0–100% VWC), temperature (−40 to +80 °C), and electrical conductivity (0–23 dS/m). EC reflects soil salinity, which affects nutrient availability, microbial activity, and crop yield — so you manage fertigation and salt build-up, not just water.

Does it need a LoRaWAN gateway?

Yes. It transmits over LoRaWAN to a gateway and network server (The Things Stack, ChirpStack, or a Milesight/SenseCAP gateway). A gateway is sold separately.

Which frequency plan does it use?

A single device supports 7 plans (EU868, US915, AU915, AS923, KR920, IN865, RU864). It ships unset and is configured on first power-up via Bluetooth — and can be switched at any time.

How long does the battery last, and is it replaceable?

Up to 10 years on a replaceable D-size ER34615 Li-SOCl₂ battery (19 Ah). Actual life depends on reporting interval, payload, and distance to the gateway.

How is it configured?

No-code setup in four steps via Bluetooth using the free SenseCAP Mate app — no programming required.

Is it suitable for outdoor / harsh conditions?

Yes. It's IP66-rated for −40 to +85 °C and passed six reliability tests (high/low temperature, conformance, waterproof, freezing, long-range, and production), making it suitable for UV, rain, and dust.

Certifications

CE FCC RoHS

Specifications
  • Primary Communication Protocol
    LoRaWAN
  • Frequency/Region
    EU868
  • Antenna Type
    Internal
  • LoRaWAN Class
    Class A
  • Radio & Range

    Protocol: LoRaWAN v1.0.3 Class A

    Frequency plans: IN865/EU868/US915/AU915/AS923/KR920/RU864 (configurable via Bluetooth)

    TX power: 19 dBm (max)

    Sensitivity: -136 dBm @ SF12, BW 125 kHz

    Range: 2 km urban / 10 km line of sight (manufacturer figure)

  • Configuration Method
    Bluetooth, Downlink
  • Activation Method
    OTAA, ABP
  • Monitoring Parameters
    Soil Moisture (VWC), Soil Temperature, Soil EC (Conductivity)
  • Measurement Range

    Soil moisture (VWC): 0–100% (air–water)

    Soil temperature: -40°C to +80°C

    Soil EC: 0–23 dS/m

  • Measurement Accuracy

    Soil moisture: ±3% (0–50%); ±5% (50–100%)

    Soil temperature: ±0.5°C (0–50°C); ±1°C (-40–0°C and 50–80°C)

    Soil EC: ±5% (0–5 dS/m); ±10% (5–23 dS/m)

  • Measurement Resolution

    Soil moisture: 0.1% (0–50%); 0.5% (50–100%)

    Soil temperature: 0.1°C

    Soil EC: 0.01 dS/m (0–5 dS/m); 0.1 dS/m (5–23 dS/m)

  • Power Source
    Battery (Non-rechargeable)
  • Power Input
    1 × 19 Ah D-size Li-SOCl2 (ER34615), replaceable, non-rechargeable
  • Battery Type
    Li-SOCl2
  • Battery Capacity
    19000mAh
  • Battery Life
    Up to 10 years (manufacturer figure)
  • Weight
    405 g
  • Mounting Options
    Pole Mount, Submerged
  • IP Rating
    IP66
  • Environment Rating
    Outdoor
  • Operating Temperature
    -40°C to +85°C
  • Certifications
    CE, FCC, RoHS
  • Warranty
    2 Years

Document Library

S2105 Datasheet

S2105 User Manual

Decoder Download
