Dragino WSS-23 | Industrial Air Quality Sensor (CO2, PM2.5, PM10)
A professional-grade air quality transmitter designed for industrial and agricultural environments to monitor carbon dioxide and particulate matter with high precision.
- Triple Monitoring: CO2 (0–5000ppm), PM2.5, and PM10 (0–1000µg/m³)
- Industrial Accuracy: ±3% FS Accuracy for Particulates | 1ppm CO2 Resolution
- Reliable Interface: RS485 Modbus Support | Optimized for WSC2-L Connectivity
Dragino WSS-23 | Industrial Air Quality Sensor (CO2, PM2.5, PM10) is backordered and will ship as soon as it is back in stock.
VAT Free Transaction Option
VAT Free Transaction Option
Our store displays prices excluding VAT by default. For EU-based businesses with a valid VAT number, intra-community VAT exemptions apply. You can validate your VAT number during the checkout process to ensure correct billing.
Secure Payment & Warranty
Secure Payment & Warranty
- Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
- B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
- Quality Guaranteed: All professional IoT hardware is backed by a 2-year manufacturer warranty and technical support from our engineering experts at shopioT.
Delivery and Shipping
Delivery and Shipping
Reliable, tracked, and fast global shipping via FedEx Express. Your professional IoT hardware is dispatched from our EU-based warehouse within 2 business days.
Dragino WSS-23 | Industrial Air Quality Sensor (CO2, PM2.5, PM10)
Description
Description
The Dragino WSS-23 is an industrial-grade environmental sensor designed for the simultaneous measurement of CO2, PM2.5, and PM10. Engineered for high-stability monitoring in greenhouses, smart factories, and urban research sites, it provides granular air quality data via a robust RS485 interface. As a core component of the Dragino weather station ecosystem, the WSS-23 bridges critical atmospheric data to LoRaWAN® networks when paired with the WSC2-L process unit, enabling automated ventilation and safety responses.
Core Capabilities
Agricultural & Industrial Applications
Technical Integration
The WSS-23 is designed to integrate natively with the Dragino WSC2-L weather station core. It supports a wide DC input range of 7-24V and requires a 3-minute preheat time for maximum CO2 accuracy. When combined with other WSS-series sensors, it forms a comprehensive meteorological solution capable of long-range data uplink via LoRaWAN®. For professional system architecture or particulate monitoring solutions, contact the ShopIoT technical team.
Specifications
Specifications
-
Primary Communication ProtocolRS485
-
Configuration MethodUSB-TTL / Serial
-
Environment RatingOutdoor, Industrial
-
IP RatingIP65
-
Operating Temperature-30°C to 70°C
-
Enclosure MaterialAluminum Alloy
-
Power ConsumptionTypical: 40mA, Max: 60mA
-
Measurement Technology
-
Measurement Range
-
Measurement Accuracy
-
Measurement Resolution
-
Interfaces (I/O)RS485 (Modbus RTU)
-
Monitoring ParametersCO2 (Carbon Dioxide), PM2.5 (Particulate Matter), PM10 (Particulate Matter)
