Milesight  |  SKU: UC502-N03GL

Milesight UC502 | LTE Cellular Multi-Interface Battery Controller

€151,00
Shipping calculated at checkout.

A carrier-grade battery-powered LTE RTU designed for versatile data acquisition from industrial sensors in off-grid environments.

  • • Rich I/O: Supports RS232, RS485, SDI-12, AI, and GPIO ports.
  • • Extreme Autonomy: 19,000 mAh replaceable battery for long-term use.
  • • Rugged Build: IP68-rated enclosure for harsh industrial environments.

VAT Free Transaction Option

Our store displays prices excluding VAT by default. For EU-based businesses with a valid VAT number, intra-community VAT exemptions apply. You can validate your VAT number during the checkout process to ensure correct billing.

Secure Payment & Warranty
  • Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
  • B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
  • Quality Guaranteed: All professional IoT hardware is backed by a 2-year manufacturer warranty and technical support from our engineering experts at shopioT.

Delivery and Shipping

Reliable, tracked, and fast global shipping via FedEx Express. Your professional IoT hardware is dispatched from our EU-based warehouse within 2 business days.

Input your company name and a valid EU VAT number at the checkout page for a VAT Free Transaction.

Description

The Milesight UC502 (LTE Version) is a professional Cellular Multi-Interface Controller engineered for reliable remote monitoring where solar power is impractical. By utilizing global 4G LTE connectivity, the UC502 provides a direct path to the cloud for diverse industrial sensors. Its versatile interface array—including Modbus RTU (RS485/232), SDI-12, and Analog Inputs—allows for the integration of pressure sensors, flow meters, and environmental probes. Housed in a waterproof IP68 enclosure and powered by a massive 19,000 mAh battery, it offers a "set-and-forget" solution for critical data acquisition in remote fields, basements, and utility stations.

Engineered for Remote Operational Stability

Carrier-Grade Durability The IP68 enclosure ensures protection against 1m submersion for 7 days, making it ideal for monitoring in high-humidity zones or flood-prone areas.
Edge Intelligence & Storage Features local data storage for up to 10,000 entries and automatic retransmission logic to protect data continuity during cellular signal loss.

Industrial Monitoring Scenarios

• Utility Sub-metering: Collect data from Modbus-enabled energy or water meters in remote commercial centers via 4G.
• Environmental Hydrology: Connect SDI-12 level probes and water quality sensors in remote riverbeds or reservoirs.
• Agriculture Tech: Monitor soil moisture and nutrients across distributed farms without the need for on-site power infrastructure.

What is in the Box?

• 1 x Milesight UC502 LTE Multi-Interface Controller
• 1 x M12 Connector Cable & Mounting Bracket Kit
• 1 x 19,000 mAh Li-SOCl2 Battery (Pre-installed)
• 1 x Quick Start Guide

Product Certifications

CE FCC IP68 RoHS

Specifications
  • Primary Communication Protocol
    NB-IoT, LTE (Cat M)
  • Antenna Type
    External (SMA)
  • Configuration Method
    NFC
  • Activation Method
    Plug & Play
  • Environment Rating
    Outdoor
  • IP Rating
    IP68
  • Operating Temperature
    -30°C to 70°C
  • Enclosure Material
    PC (Polycarbonate)
  • Battery Type
    Li-SOCl2
  • Battery Capacity
    19000mAh
  • Power Consumption
    Ultra-low (Sleep: < 100uA)
  • Measurement Technology
    • Interface Versatility: Multi-interface support (GPIO, AI, RS232, RS485, SDI-12)
    • Intelligent Processing: Local threshold alarms and change-of-state reporting
  • Measurement Range
    • Analog Input: 4-20 mA or 0-10 V (Software Switchable)
    • Digital Input: Dry contact or pulse counting support
    • Serial Port: Modbus RTU Master mode for multiple sub-devices
  • Measurement Accuracy
    • Analog Precision: 12-bit ADC for high-accuracy readings
    • Data Integrity: Local storage for up to 10,000 entries with retransmission support
  • Measurement Resolution
    • Reporting Frequency: Configurable periodic report or event-driven alarm
    • Power Management: Integrated 5V/9V/12V output to power external sensors
  • Interfaces (I/O)
    RS485 (Modbus RTU), RS232, Analog Input (4-20mA), Analog Input (0-10V), Digital Input (Dry Contact), GPIO

Document Library

UC502 LTE Datasheet

UC502 LTE User Manual
