Milesight  |  SKU: WS501-868M PN: 3W-W11-EU

Milesight WS501 | Single-Button LoRaWAN Smart Wall Switch (EU Type)

€53,00
Shipping calculated at checkout.

A professional 1-gang LoRaWAN smart switch designed for direct replacement of standard EU wall switches with local and remote control.

  • • High Reliability: Supports up to 10A resistive and 5A inductive loads.
  • • D2D Protocol: Functions as both D2D Controller and Agent.
  • • Active Monitoring: Real-time voltage, current, and power tracking.

VAT Free Transaction Option

Our store displays prices excluding VAT by default. For EU-based businesses with a valid VAT number, intra-community VAT exemptions apply. You can validate your VAT number during the checkout process to ensure correct billing.

Secure Payment & Warranty
  • Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
  • B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
  • Quality Guaranteed: All professional IoT hardware is backed by a 2-year manufacturer warranty and technical support from our engineering experts at shopioT.

Delivery and Shipping

Reliable, tracked, and fast global shipping via FedEx Express. Your professional IoT hardware is dispatched from our EU-based warehouse within 2 business days.

Input your company name and a valid EU VAT number at the checkout page for a VAT Free Transaction.

Description

The Milesight WS501 is an industrial-grade 1-Gang LoRaWAN Smart Wall Switch engineered for seamless integration into smart office and building automation projects. Designed to replace traditional 86-type EU switches, it offers high-reliability relay control for lighting and electrical appliances. Beyond simple switching, the WS501 provides detailed energy analytics and features advanced safety protocols, including overcurrent protection and a switch lock function to prevent accidental manual operation.

Advanced Control & Energy Intelligence

Milesight D2D Dual-Mode Can act as a D2D Controller to trigger other switches or an Agent to receive sensor commands in under 1 second, bypassing the gateway for local automation.
Energy & Overload Protection Continuously monitors power consumption (kWh) and electrical parameters, with configurable overcurrent thresholds to automatically disconnect and protect connected equipment.

Professional Smart Building Scenarios

• Workplace Automation: Combine with AM300 series sensors via D2D to automatically shut off lights when no motion is detected.
• Industrial Lighting: Utilize Multicast support to control groups of switches across a large facility with a single LoRaWAN command.
• Public Facilities: Enable "Switch Lock" via software to prevent unauthorized manual toggling of lights in hallways or museums.

What is in the Box?

• 1 x Milesight WS501 Smart Wall Switch (EU)
• 1 x Mounting Screw Kit
• 1 x Quick Start Guide

Product Certifications

CE FCC RoHS

Specifications
  • Primary Communication Protocol
    LoRaWAN, Milesight D2D
  • Frequency/Region
    EU868
  • Antenna Type
    Internal
  • Configuration Method
    NFC, Downlink
  • Activation Method
    OTAA, ABP
  • Environment Rating
    Indoor
  • IP Rating
    IP20
  • Operating Temperature
    -20°C to 60°C
  • Enclosure Material
    PC (Polycarbonate)
  • Power Consumption
    Max 5W
  • Measurement Technology
    • Smart Load Control: High-reliability relay supporting both local physical press and remote LoRaWAN command triggers.
    • Milesight D2D: Supports Milesight D2D protocol as both a Controller and Agent for ultra-low latency (<1s) local automation without a gateway.
    • Integrated Monitoring: Built-in sensors collect real-time data for voltage, current, power, and total electrical consumption.
    • Visualized Status: Features a configurable ice-blue LED indicator for easy operation in dark environments.
  • Measurement Range
    • Input Voltage: 100V to 250V AC, 50~60 Hz.
    • Maximum Current: 10A Resistive / 5A Inductive per gang.
    • Rated Load: Maximum 1000 W (Resistive).
    • Transmission Range: Up to 15 km (Line of Sight) or 2 km in urban environments.
  • Measurement Accuracy
    • Typical Accuracy: ±3% (Maximum ±5%, with ±1% customizable option).
    • Safety Protection: Integrated overcurrent protection and flame-retardant PC material (UL94 V0).
    • Data Reliability: Internal storage for 1,000 historical records with retransmission support to prevent data loss.
  • Measurement Resolution
    • Voltage Resolution: 0.1V.
    • Current Resolution: 1mA.
    • Energy Resolution: 1Wh (0.001 kWh).
    • Reporting Interval: Configurable from 1 to 1080 minutes (Default: 20 mins).
  • Monitoring Parameters
    Voltage (V), Current (A), Active Power (W), Power Factor, Energy (kWh), Relay Status

Document Library

WS501 Datasheet

WS501 User Manual
