PowerUC | SKU: SCT024TS-150A-5A-1%

PowerUC SCT024TS | Split-Core Current Transformer (5A Output)

€15,00

Shipping calculated at checkout.

A professional split-core current transformer featuring a 5A secondary output for seamless integration with industrial meters and power monitors.

• Split-Core Design: Easy installation without disconnecting cables.
• High Accuracy: Class 0.5 and Class 1 options for precise metering.
• Secure Housing: Flame retardant UL94-V0 with safety lock buckle.

Rated Input

Rated Output

Accuracy

VAT Free Transaction Option

Our store displays prices excluding VAT by default. For EU-based businesses with a valid VAT number, intra-community VAT exemptions apply. You can validate your VAT number during the checkout process to ensure correct billing.

Secure Payment & Warranty

Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
Quality Guaranteed: All professional IoT hardware is backed by a 2-year manufacturer warranty and technical support from our engineering experts at shopioT.

Delivery and Shipping

Reliable, tracked, and fast global shipping via FedEx Express. Your professional IoT hardware is dispatched from our EU-based warehouse within 2 business days.

Input your company name and a valid EU VAT number at the checkout page for a VAT Free Transaction.

Description

The PowerUC SCT024TS (5A Output) is a high-performance split-core current transformer engineered for non-intrusive electrical monitoring in industrial and commercial power systems. By utilizing a secure safety lock buckle, it allows for rapid "snap-on" installation around existing live conductors up to 24mm in diameter, eliminating the need to disconnect primary cables or halt operations.

Industrial Accuracy & Safety

Standardized 5A Secondary Designed with a 5A output type to ensure universal compatibility with traditional analog ammeters, digital power meters, and PLC analog inputs.

Rugged Engineering Features a laminated silicon steel core and screw terminal output, offering a wide operating temperature range from -25°C to +60°C.

Industrial Monitoring Scenarios

• Power Quality Analysis: Monitor current loads and balance across three-phase systems in industrial distribution boards.

• Energy Sub-metering: Retrofit existing panels to provide consumption data for energy management software (EMS).

• Motor Protection: Track real-time current draw for large industrial motors to prevent overcurrent and equipment failure.

What is in the Box?

• 1 x PowerUC SCT024TS Split-Core CT (5A Type)

• 1 x Technical Specification Sheet

Product Certifications

CE GB20840-2014 UL94-V0

Specifications

Primary Communication Protocol

Analog
Activation Method

Plug & Play
Environment Rating

Indoor
Operating Temperature

-25°C to 55°C
Power Consumption

Passive
Measurement Technology
- Split-Core Design: Features a safety lock buckle for rapid, non-invasive installation on existing electrical lines.
- Standardized Output: Provides a 5A secondary current output, making it compatible with most industrial power meters and energy analyzers.
- Industrial Materials: Utilizes a high-quality laminated silicon steel core for reliable inductive performance.
- Dielectric Strength: Tested at 3.5KV (50Hz/1min) to ensure electrical isolation and safety in industrial cabinets.
Measurement Range
Primary Current Input Options:
- Input Range: 100A, 150A, 200A, 250A, 300A, 400A AC.
- Rated Output: 5A AC.
- Window Size: 24mm diameter aperture for primary cables.
Measurement Accuracy
- Accuracy Class: Available in 0.5% and 1.0% classes (variant dependent).
- Phase Error: Optimized for precise energy monitoring and power factor calculation.
- Linearity: Excellent linear response across the rated current range for high-fidelity data collection.
Measurement Resolution
- Output Burden: Designed for low-impedance screw terminal connections.
- Frequency Response: Optimized for standard 50/60Hz grid frequencies.
- Transformation Ratios: Available from 1:20 (100A:5A) up to 1:80 (400A:5A).
Monitoring Parameters

Current (A)

Document Library

SCT024TS - 5A Datasheet
