Milesight EM310-UDL LoRaWAN® Ultrasonic Distance/Level Sensor - EU 868MHz
:In stock
Product Features
- 3-Axis Accelerometer
- Dual Ultrasonic Sensor
- IP67 Waterproof
- LoRaWAN® Based
- Easy Configuration (via NFC)
Share:
Product Description
With dual ultrasonic beams, the advanced EM310-UDL measures from 3 cm up to 450 cm, thus has ultra-short blind zone. Built-in 3-axis accelerometer allows you to recognize objects’ movement efficiently and reliably.
Product Specifications
| Wireless Transmission | |
| Technology | LoRaWAN® |
| Frequency | EU868 |
| Tx Power | 16dBm (868 MHz) |
| Sensitivity | -137dBm @300bps |
| Work Mode | OTAA/ABP Class A |
| Measurement | |
| Distance Detection Range | 3 – 450 cm |
| Distance Detection Accuracy | ± (1+0.3%*S) cm, S=distance |
| Distance Resolution | 1 mm |
| Device Position Status | Normal/Tilt |
| Operation | |
| Configuration | NFC Configuration via Mobile App |
| Physical Characteristics | |
| Power Supply | 2 × 3500 mAh ER17505 Li-SOCl2 Batteries |
| Battery Life | Up to 10 years (10 min interval + 20 triggers per day) |
| Operating Temperature | -15°C to +60°C |
| Relative Humidity | ≤90% (non-condensing |
| Ingress Protection | IP67 |
| Dimension | 111 × 62 × 40 mm (4.37 × 2.44 × 1.57 in) |
| Weight | 168g |
| Material & Color | ABS, Black |
| Installation | On the flat surfaces with screws |
Product Downloads
- Milesight EM310-UDL LoRaWAN® Ultrasonic Distance/Level Sensor (EU868) Datasheet
- Milesight EM310-UDL LoRaWAN® Ultrasonic Distance/Level Sensor (EU868) User Manual
