Milesight | SKU: WS558-868M PN: LN

8% off

Milesight WS558 | LoRaWAN Smart Light Controller (LN Type)

€122,00 €133,00

Shipping calculated at checkout.

A professional 8-channel LoRaWAN controller designed for high-power lighting circuits with integrated energy consumption monitoring.

• 8-Channel Control: Manage up to 8 high-power circuits.
• D2D Protocol: Direct device-to-device control without gateways.
• LN Wiring: Direct Neutral wire connection for active power data.

Frequency/Region

VAT Free Transaction Option

Our store displays prices excluding VAT by default. For EU-based businesses with a valid VAT number, intra-community VAT exemptions apply. You can validate your VAT number during the checkout process to ensure correct billing.

Secure Payment & Warranty

Encrypted Checkout: Shop with confidence via Shopify Payments or PayPal Express for fully secure, PCI-compliant transactions.
B2B Flexible Billing: For large-scale infrastructure orders, we offer Direct Bank Transfer (SEPA/SWIFT) options. Please contact our team for a pro-forma invoice.
Quality Guaranteed: All professional IoT hardware is backed by a 2-year manufacturer warranty and technical support from our engineering experts at shopioT.

Delivery and Shipping

Reliable, tracked, and fast global shipping via FedEx Express. Your professional IoT hardware is dispatched from our EU-based warehouse within 2 business days.

Input your company name and a valid EU VAT number at the checkout page for a VAT Free Transaction.

Description

The Milesight WS558 LN Type is an industrial-grade LoRaWAN Smart Light Controller engineered for comprehensive energy management and remote circuit control. This "LN Type" version requires a Neutral wire connection, enabling the device to provide precise power consumption data while managing up to 8 independent lighting circuits.

Advanced Lighting & Power Intelligence

Milesight D2D Communication Acts as a D2D Agent to receive commands directly from sensors in under 1 second, enabling gateway-free local automation for lighting and fans.

Energy & Overcurrent Monitoring Collects precise data on voltage, current, and power consumption, featuring built-in overcurrent protection to safeguard electrical assets.

Professional Smart Lighting Scenarios

• Smart Buildings: Centralized control of high-density lighting zones in malls, offices, and hotels.

• Facility Management: Real-time tracking of electrical consumption (kWh) to optimize energy budgets and identify faults.

• Bulk Control: Utilize Multicast support to control multiple units or groups of lights simultaneously via one command.

What is in the Box?

• 1 x Milesight WS558 Controller (LN Type)

• 1 x Terminal Block Kit

• 1 x Quick Start Guide

Product Certifications

CE FCC RoHS

Specifications

Primary Communication Protocol

LoRaWAN, Milesight D2D
Frequency/Region

EU868
Antenna Type

Internal
Configuration Method

NFC, USB
Activation Method

OTAA, ABP
Environment Rating

Indoor
IP Rating

IP20
Operating Temperature

-20°C to 60°C
Enclosure Material

ABS Plastic
Power Consumption

Max 5W (All Relays On)
Measurement Technology
- Active LN Output: Provides 8 channels of direct power output (100-240VAC) to connected devices, simplifying wiring for centralized loads.
- Milesight D2D Agent: Supports Milesight D2D protocol as an agent, enabling ultra-low latency (<1s) control from D2D controllers without a gateway.
- Comprehensive Power Monitoring: Tracks Voltage (V), Current (mA), Power Factor (%), Active Power (W), and total Consumption (kWh).
- Safety Interlock: Built-in overcurrent protection that automatically shuts off all switches if current exceeds 13A for more than 30 seconds.
Measurement Range
- Input Voltage: AC 100V to 240V (50/60Hz).
- Load Capacity (Resistive): Maximum 10A per output; Total 16A max across all 8 channels.
- Load Capacity (Inductive/Capacitive): Maximum 5A per output; Total 16A max across all 8 channels.
Measurement Accuracy
- Electrical Measurement: High-precision sensing for utility-grade energy monitoring and facility auditing.
- Power-Off Memory: Automatically restores the last relay status (On/Off) following a power failure.
- Transmission Range: Capable of up to 15km line-of-sight in rural environments and 2km in dense urban areas.
Measurement Resolution
- Voltage Resolution: 0.1V.
- Current Resolution: 1mA.
- Energy Resolution: 0.001 kWh (1 Wh).
Interfaces (I/O)

Active Outputs
Monitoring Parameters

Relay Status, Current (A), Voltage (V), Power Factor, Active Power (W), Power Consumption

Document Library

WS558 LN Datasheet

WS558 LN User Manual
